ASME B5.61:2003 pdf free download Power Presses: General Purpose, Single Action, Straight Side Type
1.1 Scope
THIS STANDARD APPLIES TO HYDRAULIC AND MECHANICALPOWER PRESSES COMMONLY REFERRED TO BY THE METAL-wORKING INDUSTRY AS GENERAL PURPOSE,SINGLE ACTION,STRAIGHT SIDE TYPE POWER PRESSESTHAT,BY MEANS OF DIESOR TOOLING ATTACHED TO THE SLIDE AND BOLSTER,ARE USED TOSHEAR,PUNCH, FORM,OR ASSEMBLE METAL OR OTHER MATERIALS.THE FOLLOWING TYPES OF PRESSES ARE EXCLUDED FROM THISSTANDARD:
(A)AIR (PNEUMATIC)(B) BENCH
(C) EYELET MACHINES(D) FORGING
(E) FOUR SLIDE MACHINES(F)GAP FRAME
(G) KNUCKLE JOINT(H)MULTIPLE ACTION( MULTIPLE SLIDE(J) SPOTTING
(KTRANSFER FEED(L)TURRET PUNCHING
1.2 Purpose
THE PURPOSE OF THIS STANDARD IS TO DEFINE AND DESCRIBEPOWER PRESSES AND THEIR INTERFACE,AND TO PERMIT INTER-CHANGEABILITY OF BOLSTERS, DIES,AND TOOLING COMPONENTSBETWEEN PRESSES OF COMPARABLE TYPE.SIZE,AND CAPACITY.
1.3 Application
ANY POWER PRESS DESCRIBED HEREIN AND REFERRED TOAS AN AMERICAN NATIONAL STANDARD POWER PRESS SHALLCOMPLY WITH THE APPLICABLE REQUIREMENTS DELINEATED INTHIS STANDARD.
2 DEFINITIONS AND TERMINOLoGYTERMS USED IN THIS STANDARD ARE DEFINED IN ASMEB5.49,GLOSSARY OF POWER PRESS TERMS.
3 METRIC/u.s. cUSTOMARY RATIONALIZATION
3.1 Metrication
ALL UNITS OF DIMENSION AND CAPACITY STATED HEREIN AREIN ACCORDANCE WITH ASME B5.51M,PREFERRED SI UNITS
FOR MACHINE TOOLS.APPROXIMATE U.S. cUSTOMARY UNITSARE HISTORICAL STANDARDS AND ARE FOR REFERENCE ONLY. WHER-EVER USED IN THIS STANDARD,THE UNIT TONS DENOTES U.s.TONS.
3.2 Metric/U.s. Customary Conversion
NONMANDATORY APPENDIX A PROVIDES CONVERSIONMULTIPLIERS APPLICABLE TO THIS STANDARD.
4 PRESS CHARACTERISTICS
4.1 Rated Capacity
STANDARD CAPACITY RATINGS SHALL BE AS SPECIFIED INTABLE 1 (SEE ALSO FIG.1).SEE NONMANDATORY APPENDIX BFOR HISTORICAL COMPARISON OF CAPACITY RATINGS.
4.2 Rating Points (Mechanical Power Press)
(A)STANDARD RATING POINTS SHALL BE AS SPECIFIED INTABLE2.
(B) DRIVE DESIGN SHALL BE BASED ON PROVIDING THE
TORQUE, WHICH PRODUCES THE RATED PRESS CAPACITY AT THERATING POINT(SEE FIG.2).
(C) PRESS CAPACITY AT POINTS OTHER THAN THE RATING POINTARE SHoWNIN
( 1)MANDATORY APPENDIX I FOR PRESSES RATED AT12.7 MM(V 2 IN.)
(2)MANDATORY APPENDIX II FOR PRESSES RATED AT6.3 MM(√ 4 IN.)
(3) MANDATORY APPENDIX III FOR PRESSES RATED AT 1 .6 MM ( 1 ⁄ 1 6 IN.) 4.3 Energy Capacity (Mechanical Power Press)
4.3.1 Function of the Flywheel. THE ENERGY REQUIRED FOR PERFORMING PRESS OPERATIONS IS STORED IN THE FLYWHEEL. DURING THE WORKING PORTION OF THE PRESS CYCLE, THE FLY- WHEEL SLOWS DOWN AS IT SUPPLIES THE REQUIRED ENERGY TO THE DRIVE TRAIN.
