ASME B18.8.1:2014 pdf free download Clevis Pins and Cotter Pins (Inch Series)
1INTRODUCTION1.1 Scope
1.1.1 This Standard covers the complete dimen-sional and general data for clevis pins sizes 3/16 in.through 2 in. and cotter (split) pins sizes /s2 in. through3/4in. of various materials.
1.1.2 The inclusion of dimensional data in thisStandard is not intended to imply that all productsdescribed are stock production items.Consumers shouldconsult with suppliers concerning the availability ofproducts.
1.1.3 There is no ISO standard comparable to thisStandard.
1.2 Dimensions
All dimensions in this Standard are given in inchesand apply before plating or coating. Tolerancing is inaccordance with ASME Y14.5.
1.3 Responsibility
The responsible party for the performance of the prod-ucts within the scope of this Standard is the organizationthat supplies the components to the purchaser and certi-fies or represents that the component was manufactured,tested, and inspected in accordance with this specifica-tion and meets all of its requirements.
1.4 Inspection and Quality Assurance
Unless otherwise specified by the purchaser, accept-ability shall be based on conformance with the require-ments specified in ASME B18.18.
1.5 Terminology
For definitions of terms relating to pins or featuresthereof used in this Standard, refer to ASME B18.12.
1.6 Reference Standards
ASME B18.12,Glossary of Terms for MechanicalFasteners
ASME B18.18,Quality Assurance for FastenersASME Y14.5,Dimensioning and Tolerancing
Publisher: The American Society of MechanicalEngineers (ASME),Two Park Avenue, New York,NY10016-5990; Order Department: 22 Law Drive,P.O.Box 2900,Fairfield,NJ 07007-2900 (www.asme.org)
ASTM A153/A153M,Standard Specification for ZincCoating (Hot-Dip) on Iron and Steel HardwareASTM A380,Standard Practice for Cleaning, Descaling,and Passivation of Stainless Steel Parts,Equipment,and Systems
ASTM A493,Standard Specification for Stainless SteelWire and wire Rods for Cold Heading and ColdForging
ASTM A751,Standard Test Methods, Practices, andTerminology for Chemical Analysis of Steel ProductsASTM B134/B134M,Standard Specification for BrassWire
ASTM E384,Standard Test Method for Knoop andVickers Hardness of Materials
ASTM F1941,StandardSpecification forElectrodeposited Coatings on Threaded Fasteners(Unified Inch Screw Threads (UN/UNR))
ASTM F2329,Standard Specification for Zinc Coating,Hot-Dip, Requirements for Application to Carbon andAlloy Steel Bolts, Screws,Washers, Nuts, and SpecialThreaded Fasteners
Publisher: ASTM International,100 Barr Harbor Drive,P.O.Box C700,West Conshohocken,PA 19428-2959(www.astm.org)
SAE J864,Surface Hardness Testing With Files
Publisher: SAE International,400 Commonwealth Drive,Warrendale, PA 15096-0001 (www.sae.org)
GENERAL DATA -CLEVIS PINS
2.1 Clevis Pin Application
The clevis pins covered herein are intended for generalapplications.The clevis pins specified are intended foruse in conjunction with clevises and rod end eyes, andthe cotter pins contained herein.Tables 1 and 2 containdimensional data relative to clevis pin dimensions.2.2 Clevis Pin Head
2.2.1 Clevis Pin Top of Head. The top of the headshall be flat and either chamfered or rounded at outerperiphery.
2.2.2 Clevis Pin Bearing Surface.The bearing sur-face of the head shall be flat and square with the axisof pin (determined over a distance from under the headequivalent to 1.5 times the basic pin diameter) within2 deg.
