ASME A112.19.19:2006 pdf free download Vitreous China Nonwater Urinals
wWhen alternate materials are used as componentswithin a nonwater urinal, the assembly shall conformto applicable material standards for the plumbing appli-cation. They shall satisfy this Standard regarding quality,strength, effectiveness, durability, and safety. They shallalso be repairable or replaceable within the vitreouschina fixture.
3.2 Alternate Materials in Trapways
wWhere alternate materials are used in a nonwater uri-nal trapway, the trapway shall comply with the require-ments of the auger test specified in para.5.5.
3.3 Nonstandard Outlet Configurations – Joint SealTest
When an outlet configuration requires a connectionother than a urinal flange, this connection shall not leakwhen tested in accordance with para. 5.7 and shall beof a design that allows for field repair or replacement.
3.4Load Tests for Wall-Mounted Fixtures
3.4.1 Load Test for Urinals. All wall-mounted, non-water urinals shall withstand a load of 50 lbf (0.22 kN)
when tested in accordance with para.5.6.
3.4.2 Off-the-Floor Fixture Supports.Fixture sup-ports,when required, shall comply with ASMEA112.6.1M,ASME A112.6.2,or ASME A112.19.12.
3.5 Tolerances and Dimensions
For tolerance and dimension information,referenceASME A112.19.2, para.3.1.
3.6 Connection to the Drainage System
3.6.1 Nonwater urinals shall have an integral orremovable trap with a liquid seal and an outlet assemblyfor connection to the drainage system.The outlet spudsize shall be a minimum of 1/ in. (38 mm) in diameter.3.7 Urinal Dimensions
Minimum urinal dimensions shall be as specified inTable 2.
MARKINGS AND INSTALLATION INSTRUCTIONS4.1 Permanent Markings on Product
Each fixture meeting this Standard shall be perma-nently marked as required by this section. where thefixture is comprised of two or more components, eachfixture component that is visible after installation of thefixture shall be permanently marked as required by thissection.Acceptable means of applying permanent mark-ings shall include fired on, etching, sand blasting,stamp-ing with a permanent (nonwater soluble) ink, and cast-in markings.Adhesive labels that comply with UL 969shallalso be considered permanent.The exposure conditionscontained in para.7.1 of UL 969 shall apply, along withthe additional exposure to the detergent test specifiedin Table 7.4 of UL 969.
4.1.1 Manufacturer’s Name.The manufacturer’sname or registered trademark or, in the case of privatelabeling, the name of the customer for whom the fixturewas manufactured shall be applied so as to be legible,readily identified, and located so as to be visible afterinstallation.
4.1.2 Model Number. The model number of thenonwater urinal shall be applied so as to be legible.4.1.3 Date of Manufacture. The date of manufacture(casting date) shall be applied so as to be legible.
4.2 Marking Requirements for Product PackagingAll packaging for vitreous china nonwater urinalsshall be marked with the manufacturer’s name or regis-tered trademark or, in the case of private labeling, thename of the customer for whom the fixture was manu-factured and the model number of the fixture.
4.3 Installation lnstructions
The manufacturer shall provide installation instruc-tions with the nonwater urinals. Installation instructionsshall include care and maintenance information.
4.4Repair Parts
The manufacturer shall supply information to enabletheend user to specify and obtain repair parts for normalmaintenance.
5 VITREOus CHINA AND ALTERNATE MATERIALSTESTS
5.1 Absorption (Boiling)Test
For absorption (boiling) test criteria, referenceASME A112.1i9.2, para.7.1.
5.2 Crazing Test
For crazing test criteria, reference ASME A112.19.2,para.7.2.
5.3 Warpage Test
For warpage test criteria, reference ASME A112.19.2,para. 7.3 (see also para. 2.4).
5.4 Evaluation of Surface Finish
For surface finish criteria, reference ASME A112.19.2,para.7.4 (see also para. 2.6).
