GENERAL1.1 Scope
This Standard cstablishcs matcrial,mechauical, elec-trical，marking,and testing requiremcnts for bathtubslwhirlpool bathtubs with doors that are made water tightby the use of a pressure seal. It addresses the functionalperformance and physical characteristics for a pressuresealed door of a bathtub/whirlpool bathtub.
The door is intended to ailow for entry into thefixture when the tub is empty.and maintains watertightness when the lub is fuil.
The use of alternate maierials or methods are permit-ted,provided the proposed material and method com-plies with the performance requirements and intent ofthis Standard.
1.2 Units of Measurement
Values are stated in U.s. Customary units and theInternational System of Units (SI). The U.s. Customaryunits shall be considered as the standard.
1.3 Reference Standards
The foiiowing documents form a part of this Standardto the extent specified herein. The latest issue shallapply.
ASTM D2000,Standard Classification System for Rub-ber Products in Automotivc Applications
Pubisher: The American Socieiy for Testing and Miateri-als (ASTM),100 Barr Harbor Drive,West Consho-hocken,PA 19428
ANSI Z124.1，Plastic Bathtub Units
Publisher: International Association of Plumbing andMechanical Offcials (IAPMO),20001 Walnut Drive,South Walnut,CA 91789-2096
ASME A112.19.4M,Porcelain Enamcled Formed SteclPlumbing Fixtures
ASME A112.19.7M,Whirlpool Bathtub AppliancesPublisher: The Americal Society of Mcchanical Engi-neers (ASME International),Three Park Avenue,New York,NY 10016
UL 1795，Hydromassage Bathtubs
Publisher: Undcrwritcr’s Laboratories (UL),333 Pfings-ten Road，Northbrook,IL 60062
1.4 Definitions
primary seal (pressure seal): a main water barrieractivated by hydraulic，air，compression，or dis-placement.
secondary seal:a redundant water barrier to the pri-mary seal.
2 GENERAL REQUIREMENTS2.1 Materials
The materials incorporated in the door and compo-nents of the seals shall be made of plastics,rubbers.or other material suitable for application in plumbingfixtures or devices,or in accordance with the standardsrcfcrenced in this Standard. The bathing shell shallmeet all of thc applicable requirements of ANSI Z124.1or ASME A112.i9.4M and a whirlpool bathtub shallmeet all the requirements of ASME A112.19.7M.2.2 Door
The bathtub door shall meet the performance critcriaas specified in section 3 of this Standard.
2.3 Electrical Components
Electrical components shall meet the applicable re-quirements of UL 1795.
2.4 Door And Seals
The door shall have a minimum of one of thefollowing:
(a) Primary and secondary seal，or
(b) Seal with adequate means for drainage.
The door drain shall be designed as an integral partof the bathing unit. Units with primary and secondaryscals and without a catch basin shall not permit anyleakage of the primary seal.
2.5 Primary Seal Materiais
The primary seal material shall meet the followingrequirements of ASTM D2000;
a)The primary scal shall be heat aged a 257°F(125°c) for 70 hr.
(b)The primary scal shall have a maximum walerabsorption of no more than 5% after 70 hr of sustainedheat of 212F (100°C).
(c)The primary seal material shall have a minimumtear resistance of 1782 1bf/ft (26 kN/m).
TESTING
Test shall be conducted in thc following sequence.3.1 Secondary Seal
Any secondary scal shall have a leakage of not morethan 2 gal (1.9 L)in 20 min with the tub filled tothe overflow level and the primary seal disabled..3.2 Door Load Test
The door shall withstand a three hundred 300 lb(136 kg) vertical load when the door is open at 45deg position. The load shall be placed on the ‘top edgeof the door on the opposite end from the hinge post.Deflection under load shall be less than 0.625 in. (16mm). Afier the ioad test is completed, the door and
