1 Scope
1.1
This Standard specifies requirements for manually operated valves, also known as supply line stops, insizes NPS 4 and smaller.
1.2
Valves covered by this Standard are intended for
a)installation as water shutoff valves between the meter and the supply stop; and
b)service at temperatures between 5 °C(40 °F) and 71 °℃(160 °F), with an allowable working
pressure rating not less than 862 kPa (125 psi).
1.3
This Standard does not apply to hose end valves or endpoint devices as defined in Section 9 of NSF/ANSI61.
1.4
ln this Standard, ” shall” is used to express a requirement, i.e., a provision that the user is obliged tosatisfy in order to comply with the standard; “should” is used to express a recommendation or thatwhich is advised but not required; and “may” is used to express an option or that which is permissiblewithin the limits of the Standard.
Notes accompanying clauses do not include requirements or alternative requirements; the purpose of anote accompanying a clause is to separate from the text explanatory or informative material.
Notes to tables and figures are considered part of the table or figure and may be written asrequirements.
Annexes are designated normative (mandatory) or informative(non-mandatory) to define theirapplication.
1.5
sl units are the units of record in Canada. ln this Standard, the yard/pound units are shown inparentheses.
The values stated in each measurement system are equivalent in application; however, each system is tobe used independently.Combining values from the two measurement systems can result in nonconformance with this Standard.
All references to gallons are to u.s. gallons.
For information on the conversion criteria used in this Standard, see Annex A.
2 Reference publications
Th is Standard refers to the following publications , and where such reference is made , it shall be to the edition listed below , including all amendments published thereto .
ASME (The American Society of Mechanical Engineers)/CSA Group
ASME Al1 2 .1 8.1 -201 2jCSA B125.1 -201 2
Plumbíng supply fíttíngs
ASME (The American Society of Mechanical Engineers)
B 1. 1-2003 (R2008)
Unífíed Inch Screw Threads , (UN and UNR Thread Form)
B 1. 20.1-2013
Pípe Threads , General Purpose , Inch
B16 .1 8-201 2
Cast Copper Alloy Solder Joínt Pressure Fíttíngs
B16 . 22 -201 3
Wrought Copper and Copper Alloy Solder Joínt Pressure Fíttíngs
B1 6.26-201 3
Cast Copper Alloy Fíttíngs for Flared Copper Tubes
B16 . 51 -201 3
Copper and Copper Alloy Press-Connect Pressure Fíttíngs
CSA B137 .5 -1 7
Crosslínked polyethylene (PEX) tubíng systems for pressure applícatíons
CSA B137.6-1 7
Chlorinated (CPVC) pipe , tubíng , and for hot – and cold- water dístríbution systems
ASSE (American Society of Sanitary Engineering)
1 061 -201 5
Performance Requírements for Push-Fít Fíttíngs
ASTM International (American Society for Testing and Materials)
D1 599-201 4e1
Standard Test Method for Resístance to Short- Ti me Hydraulic Pressure of Plastíc Pípe , Tubíng , and Fíttings
D1784-2011
Standard with Specification for Rigid Poly (Vinyl Chloride) (PVC) Compounds and Chlorinated Poly (VinylChlorinated)(cPvc) compounds
D2466-2015
Standard Specification for Poly (Vinyl Chloride)(PVC) Plastic Pipe Fittings, Schedule 40
D2467-2015
Standard Specification for Poly (Vinyl Chloride)(PVC) Plastic Pipe Fittings, Schedule 80
D2846-2014
Standard Specification for Chlorinated Poly (Vinyl Chloride)(CPVC) Plastic Hot- and Cold- WaterDistribution Systems
E29-2013
Standard Practice for Using Significant Digits in Test Data to Determine Conformance with Specifications
F439-2013
Standard Specification for Chlorinated Poly (Vinyl Chloride)(CPVC) Plastic Pipe Fittings, Schedule 80
F1498-2008(2012)e1
Standard Specification for Metallic Mechanical Fittings for Use on Outside Diameter ControlledThermoplastic Gas Distribution Pipe and Tubing
F1970-2012e1
Standard Specification for Special Engineered Fittings,Appurtenances or Valves for use in Poly (VinylChloride) (Pvc) and chlorinated Poly (Vinyl Chlorinated)(CPvC) systems
AwwA (American Water Works Association)
c606-2015
Grooved and Shouldered Joints
NSF International
NSF/ANSI 61-2016
Drinking Water System Components — Health Effects
NSF/ANSI 359-2016
Valves for Crosslinked Polyethylene(PEX) Water Distribution Tubing Systems
NSF/ANSI 372-2016
Drinking Water System Components -Lead content
